NEO M8N GPS Module with Compass for APM ArduPilot Arducopter

₹2,399.00
In stock
SKU
PRO623

Adding a GPS Module to your APM Flight controller let you fly autonomous flights. This is the latest high accuracy NEO M8N GPS Module for the APM Flight controller with onboard compass. The NEO M8N offers upto 0.6m(compared to 1.5m accuracy or previous NEO 7M and 6M modules) accuracy in optimal conditions. Ublox NEO M8N is upgraded on the and offers low power consumption, high precision, supports GPS+GLONASS dual positioning system, improves the search speed and reception, effectively reducing the HDOP value compared to previos NEO 7M and 6M Versions.

This module is plug and play with the APM and requires no external circuit/connections or connectors. Package included double sided adhesive to mount the GPS on your drone. Use this module to run autonomous flights with your APM Arducopter Quadcopter. The GPS Module also includes an onboard compass that can be used enstead of the internal compass on the APM for better flight performance.

The Module comes with all the required cables to connect it to your APM.

Fetaures:

  • NEO-M8N Ublox/u-blox GPS Module for MWC/APM
  • These are pre-configured, flashed with the correct settings, and tested making them plug and play.
  • Position accuracy: 2.0 m CEP
  • Quick satellite searching, only need 10s to find 6 satellite in open space
  • Built-in compass, refresh rate up to 10GHz
  • Support GPS+BD+SBAS, or GPS+GLONASS+SBAS
  • Receiver type 72-channel u-blox M8 engine
  • GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1 SBAS L1 C/A: WAAS, EGNOS, MSASGalileo-ready E1B/C (NEO-M8N)
  • Nav. update rate1 Single GNSS: up to 18 HZ
  • Concurrent GNSS: up to 10 Hz
  • Acquisition2 Cold starts: 26 s
  • Aided starts: 2 s
  • Reacquisition: 1.5 s
  • Sensitivity Tracking & Nav: –167 dBm
  • Cold starts: –148 dBm
  • Hot starts: –156 dBm
  • Assistance AssistNow GNSS Online
  • AssistNow GNSS Offline (up to 35 days)3
  • AssistNow Autonomous (up to 6 days)
  • OMA SUPL & 3GPP compliant
  • Oscillator TCXO (NEO-M8N/Q),
  • Crystal (NEO-M8M)
  • RTC crystal Built-In
  • Noise figure On-chip LNA (NEO-M8M). Extra LNA for lowest noise figure (NEO-M8N/Q)
  • Anti jamming Active CW detection and removal. Extraonboard SAW band pass filter (NEO-M8N/Q)
  • Memory ROM (NEO-M8M/Q) or Flash (NEO-M8N)
  • Supported antennas: Passive
  • Operating temp. –40° C to 85° C
  • Storage temp. –40° C to 85° C (NEO-M8N/Q)
  • –40° C to 105° C (NEO-M8M)
  • Timepulse Configurable 0.25 Hz to 10 MHz


Package includes:
  • 1 x NEO M8N GPS Module
