JST Connector SH1.0mm Assorted Socket Kit 3 to 12 Pin, Pre-Crimped Cables with Heat Shrink

 Specifications

• Connector Type: JST SH, 1.0mm pitch, pre-crimped cable, plug-in disconnectable
• Pin Range: 3 to 12 pins (10 distinct housing sizes)
• Cable Type: Pre-crimped, multi-colored (10 colors), silicone-insulated
• Voltage Rating: 50V
• Current Rating: 1A
• Housing Material: Plastic (white)
• Included Accessories: Heat shrink tubing (pre-cut, black)
• Assembly Required: None  wires arrive pre-crimped and ready to insert into housings

Minimum hardware

• Scissors or wire cutters  for trimming pre-crimped wires to your exact needed length if the included 15cm length is longer than needed
• Heat gun or lighter (careful, low flame)  to shrink the included heat shrink tubing over any exposed connections,That's it  no crimping tool or soldering iron required for basic assembly

Safety Warnings

• Pre-Crimped Reliability Note: Since these terminals arrive already crimped, you can't fix a bad crimp yourself  inspect each terminal visually before use, and if a connection feels loose in testing, use a different wire from the bundle rather than trying to re-crimp it
• Heat Shrink Warning: When using a heat gun or lighter, keep the heat source moving and avoid prolonged direct contact  melting the underlying wire insulation defeats the purpose of the heat shrink
• Pinout Warning: Always verify your target device's pinout before inserting wires into a housing  this kit provides generic housings, not device-specific pin assignments

Accessories Included in the Box

• Pre-crimped multi-colored wires (10 colors, silicone-insulated)
• SH1.0 Housings, 3P through 12P (10 sizes)
• Heat shrink tubing (pre-cut, black)

Frequently Asked Questions

• Are these pre-crimped terminals compatible with the 2-5P hand-crimp SH1.0 kit sold separately?
  Yes, both kits use genuine SH1.0mm pitch connectors, so housings and terminals are physically compatible, though this kit's terminals come pre-crimped and cannot be re-crimped if removed.
• Will this work with my DJI O3 Air Unit or SpeedyBee stack?
  Yes, this connector standard is explicitly used by DJI O3 Air Units and confirmed compatible with Probots' own SpeedyBee F7 V3 Stack product.
• Does this kit cover higher pin counts than the 2-5P kit?
  Yes, this kit spans 3 to 12 pins, a wider range than the 2-5P hand-crimp kit, making it suitable for more complex multi-signal connections.
• Can I mix pre-crimped wires from this kit with housings from the 2-5P kit?
  Yes, as long as the pin count matches, since both are genuine SH1.0mm parts
• What's the maximum current these pre-crimped terminals can safely carry?
  Rated at 1A, consistent with the JST SH series official specification.

• What's the voltage rating for this connector series?
  Rated up to 50V, consistent with JST SH's official specification.

• Can I use this for GPS or telemetry module power connections?
  Yes, this is a common and appropriate use case for SH1.0 pre-crimped cables in flight controller ecosystems..
• Do I need to know my device's pinout before using this kit?
  Yes, always verify your specific device's pinout documentation before inserting wires  this kit provides generic housings without a fixed pin assignment.

• Can I cut the pre-crimped wires to a shorter length?
  No, once cut, the pre-crimped terminal is removed and cannot be re-attached without a crimping tool  measure carefully before cutting, or use the full 15cm length if in doubt.

• How do I know which housing size matches my device?
  Count the pins on your target device's connector and select the matching housing size from the 3-12P range included.
• Why does one of my pre-crimped wires feel loose in the housing?
  This may be a factory crimp that wasn't fully seated  try a different wire from the bundle rather than attempting to fix the crimp yourself.

• Can I re-crimp a wire if I cut it too short?
  Not without a dedicated SH1.0 crimping tool  this kit's convenience trade-off is that cut wires can't be easily re-terminated.

• Why won't the housing accept the pre-crimped terminal?
  Confirm you're using an SH1.0-specific housing and that the terminal isn't bent or damaged from handling.

• The heat shrink isn't shrinking evenly  what am I doing wrong?
  Keep the heat source moving in a circular motion rather than holding it in one spot, which can cause uneven shrinking or melt the underlying wire insulation.
