CD4028 BCD to Decimal Decoder IC DIP-16 Package

₹21.00 ₹ 17.8 + 3.2 GST
In stock
SKU
PRO2938
  • BCD-to-decimal decoding or binary-to-octal decoding
  • High decoded output drive capability
  • "Positive logic" inputs and outputs……decoded outputs go high on selection
  • Medium-speed operation… tPHL, tPLH = 80 ns (typ.) @ VDD = 10 V
  • Standardized, symmetrical output characteristics
  • 100% tested for quiescent current at 20 V
  • Maximum input current of 1 µA at 18 V over full package-temperature range; 100 nA at 18 V and 25°C
  • Noise margin (full package-temperature range) =
        1 V at VDD = 5 V
        2 V at VDD = 10 V
        2.5 V at VDD = 15 V
  • 5-V, 10-V, and 15-V parametric ratings
  • Meets all requirements of JEDEC Tentative Standard No. 13B, "Standard Specifications for Description of ’B’ Series CMOS Devices"
  • Applications:
    • Code conversion
    • Indicator-tube decoder
    • Address decoding-memory selection control



Specifications:-

Parameter Specification
Part number CD4028B
Function Decoder
Technology Family CD4000
VCC (Min) (V) 3
VCC (Max) (V) 18
Channels (#) 1
Voltage (Nom) (V) 5, 10, 15
F @ nom voltage (Max) (MHz) 8
ICC @ nom voltage (Max) (mA) 0.3
tpd @ nom Voltage (Max) (ns) 160
Configuration 04:10
Type Standard
IOL (Max) (mA) 1.5
IOH (Max) (mA) -1.5
Rating See Data Sheet
Operating temperature range (C) -55 to 125
Package Group PDIP|16
Package size: mm2:W x L (PKG) 16PDIP: 181 mm2: 9.4 x 19.3 (PDIP|16)
Bits (#) 10
Digital input leakage (Max) (uA) 5
ESD CDM (kV) 0.75
ESD HBM (kV) 2
