EDR-120-48 Mean well SMPS - 48V 2.5A 120W Din Rail Metal Power Supply

₹2,465.00 ₹ 2088.98 + 376.02 GST
Out of stock
SKU
PRO3010

This is a high quality AC to DC power supply, which uses the SMPS technology for better efficiency and reliability. It outputs 48V and has maximum load capacity of 2.5A.

Key Specifications:-



  • Output Voltage          48V
  • Type                         DIN Rail Type
  • Approx. Wattage       120W
  • Features                   Standard
  • Series                      EDR(Economical)
  • Mechanical Form       DIN Rail
  • Warranty                  2 Years Warranty
  • IP Level                    Non-Waterproof
  • Input Voltage            100-240V auto-select

Features:-

  •
  • Universal AC input / Full range
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Cooling by free air convection
  • Can be installed on DIN rail TS35 / 7.5 or 15
  • UL508 (industrial control equipment) listed
  • EN61000-6-2 (EN50082-2) industrial immunity level
  • 100% full load burn-in test
  • Low cost
  • 3 years warranty for NDR series
  • 2 years warranty for EDR series

Specifications:-

  • AC input voltage range 90~264VAC; 127~370VDC
    AC inrush current (max.) Cold start, 35A at 230VAC
    DC adjustment range 12V: 12~14V, 24V: 24~28V, 48V: 48~55V
    Current adjustment range 10%~100% rated output current adjustable by 1~10Vdc, PWM signal or resistance
    Overload protection 105%~130% Constant current limiting, auto-recovery
    Over voltage protection 14V: 14~17V, 24V: 29~33V, 48V: 56~65V Shut down o/p voltage, re-power on to recover
    Over temperature protection Shut down o/p voltage, re-power on to recover
    Withstand voltage I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
    Working temperature -20~+60!aC (refer to output derating curve
    Safety standards UL60950-1, TUV EN60950-1 approved
    EMC standards EN55022 classA, EN61000-3-2(125W for EDR-150),3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2(EN50082-2)
    Connection (screw DIN terminal) I/P: 3 poles, O/P: 4 poles
    Dimension (LxWxH) (mm) 40x 125.2x 113.5
