Auto - Manual / Changeover Cam Operated Rotary Selector Switch S6 B13 6A SALZER (L&T)

Rating:
86%
Rotary Switch
β‚Ή250.00 β‚Ή 211.86 + 38.14 GST
Out of stock
SKU
PRO3089

1-3 Days Express Shipping in India Available

Deliver to
Bulk Pricing
QTYUnit Price(Inlc. GST)
25+ β‚Ή245.00 β‚Ή 207.63 + 37.37 GST
50+ β‚Ή240.00 β‚Ή 203.39 + 36.61 GST
75+ β‚Ή235.00 β‚Ή 199.15 + 35.85 GST
100+ β‚Ή230.00 β‚Ή 194.92 + 35.08 GST

Contact us for Higher Quantities.

Contact us for Higher Quantities
Not available for pickup right now
Cam Switches are suitable for AC as well as DC switching applications. These Auto-Manual / Changeover Switch are used in the Auto/Manual Changeover, Standby/Remote Changeover, and other special application circuits. Mainly used in Distribution Panels, UPS, etc.

The basic operating mechanism of Cam Switch is intended to suit applications coupled with ‘Quick-Make’, ‘Quick-Make-Quick-Break’, and ‘Spring Return’ operating mechanisms.
The CAM Switches offer versatile mounting options in addition to standard panel/flush mounting for various needs. The wide option such as type of knob, front plate color, and customized marking on the marking plate eliminates the need for a separate label on the panel.
Superior quality of engineering material and ‘double butt’ contacts with silver bimetal on copper/brass provide stable electrical performance. The high-grade engineering plastics with high tracking index like nylon, silicon, and glass-filled polyamide for the components ensure greater mechanical strength. Advanced manufacturing processes for CAM Switch components under stringent quality conditions ensure durability, reliability, and enhanced life.
The construction and design of the switch make it compact, safe, and highly reliable. The switch uses polyamide glass-filled material, having excellent track resistance (CTI) for insulation to prevent flashover between phases in the most severe conditions. The special contact design and configuration make the switch highly reliable to withstand high short circuit currents.
The same Model is available with multiple poles and current ratings. For any enquires contact us directly.

Struggling with unreliable switching between automated and manual control systems
When managing industrial processes, generators, or backup power systems, seamlessly transitioning between automatic control (like a PLC) and manual override is critical. You can't rely on flimsy toggle switches that fuse under load or fail to isolate circuits completely. The Salzer S6 B13 Auto-Manual Changeover Cam Operated Rotary Switch provides the robust, break-before-make isolation your critical infrastructure demands.

Specifications

  • Switch Type: Auto - Manual / Changeover Cam Operated Rotary Selector
  • Model Profile: Salzer (L&T) S6 B13 Series
  • Rated Current: 6A
  • Contact Mechanism: Double-break, 'Double Butt' contacts (bimetal on copper/brass)
  • Insulation Material: High-grade glass-filled polyamide (Excellent CTI)
  • Protection Rating: IP20 (Finger Protection at terminals)
  • Terminals: Fixed clamp terminal screws with clear polycarbonate protective shroud
  • Mounting Style: Standard panel / flush mounting (Enclosure compatible)
  • Operating Mechanism: Quick-Make / Quick-Break for minimal arcing

Applications

  • Control Panels: Switching between PLC (Auto) and local pushbutton (Manual) control.
  • Backup Power Systems: Manual changeover routing for secondary power supplies.
  • Motor Control Centers (MCC): Selecting between automated VFD control or direct manual override.
  • HVAC Systems: Bypassing automated thermostats for manual fan or compressor testing.

Unlock New Capabilities

  • Past Projects (Prerequisites): If you've previously built simple single-source power circuits or basic relay logic boards, you're ready to tackle redundant systems.
  • The Feature Upgrade: This changeover switch unlocks true system redundancy. It allows you to wire an automated controller (like a PLC or microcontroller relay array) on one throw, and a manual hardwired override on the other, ensuring your system can always be operated safely even if the automation fails.
  • Effort / Requirements: Advanced. Requires strong knowledge of phase isolation, AC/DC high-power wiring, and control panel design.
  • Virtual Technician & Wiring: ⚠️ SAFETY WARNING: This component is designed to route potentially lethal mains voltage. Always isolate and lock out power sources before wiring.
  • Wiring Protocol: Strip wires cleanly and use insulated ferrule crimps. The fixed clamp terminals will securely hold the ferrule. Ensure that your 'Auto' source and 'Manual' source are wired to their respective isolated throws, with the common output heading to your load. Always snap the included polycarbonate shroud over the terminals after tightening.

Package Includes:

  • 1 x Auto - Manual / Changeover Cam Operated Rotary Selector Switch S6 B13 6A SALZER (L&T)

Frequently Asked Questions (FAQ)

  • What is an Auto-Manual changeover switch used for?
    It is used to physically toggle a machine or circuit between an automated control source (like a PLC) and a manual control source (like an operator pushbutton).
  • What does the S6 B13 designation indicate?
    S6 refers to the frame size and 6A current rating, while B13 dictates the specific cam switching logic and contact configuration designed by Salzer.
  • Is this switch rated for AC or DC current?
    It is primarily designed for AC industrial control circuits. While it can switch DC, the current rating must be significantly derated due to DC arcing characteristics.
  • What is the maximum continuous current rating?
    This specific Salzer model is rated for a 6A continuous load.
  • Does this switch have a center "OFF" position?
    Typically, Auto/Manual selectors are 2-position (Auto-Manual) or 3-position (Auto-Off-Manual). Check the specific faceplate logic for your routing needs.
  • Can I use this for direct 3-phase motor control?
    At 6A, it is generally used for control circuits (switching the contactor coils) rather than directly carrying heavy 3-phase motor loads.
  • What is the housing made of?
    It is constructed from glass-filled polyamide, which provides exceptional mechanical strength and heat resistance.
  • Why is a high Comparative Tracking Index (CTI) important?
    A high CTI means the plastic insulation strongly resists electrical breakdown and tracking (carbon paths forming), which prevents catastrophic flashovers between terminals.
  • Does the switch come with a protective shroud?
    Yes, it includes a clear polycarbonate shroud that covers the wiring terminals after installation.
  • What does IP20 finger protection cover?
    IP20 ensures that a human finger cannot accidentally come into contact with live electrical terminals once the switch is properly wired and the shroud is in place.
  • Are the contacts solid silver?
    They utilize a silver bimetal layer bonded to a copper/brass base, providing the optimal balance of high conductivity and mechanical durability against repetitive strikes.
  • How does the double break contact mechanism work?
    It breaks the circuit at two distinct points simultaneously. This rapidly extinguishes electrical arcs, significantly extending the lifespan of the switch.
  • Can this switch handle short circuit currents?
    Yes, the robust mechanical design and high-quality plastics allow it to withstand high short-circuit currents without welding the contacts shut or melting the housing.
  • Do I need to buy a separate label for my panel?
    No, the switch comes with a customized front marking plate (e.g., Auto/Manual) that eliminates the need for external stickers or engraved tags.
  • What type of wire is recommended for the terminal clamps?
    Industrial stranded copper wire, properly terminated with insulated wire ferrules, is highly recommended for the most secure and reliable connection.

More Information
Technical Details

Specifications:

Parameter Description
Rated Operational Voltage(Ue) 440VAC
Rated Operational Current(Ie)Β  6
Operating frequency 50 to 60Hz
Operating temp -15 C to 55 C
Humidity 95%
