20g - 10 kg Force & Pressure Sensor Flexible Precision Thin Film RP-S40-ST

₹749.00 ₹ 634.75 + 114.26 GST
In stock


This is Force/Pressure sensor can measure a force of 20g-10 kg acting on it. It is simple and easy to use with Arduino, Raspberry Pi, and other microcontrollers. It uses Thin Film technology and is flexible. Great for general purpose project applications. It has two pin interface which is simple and easy to use. It works like a variable resistor. The resistance between the two output pins varies corresponding to the force acting on the sensor! Your microcontroller - Arduino, Raspberry Pi, etc can measure this resistance using its inbuilt ADC and get the force acting on the sensor. This sensor makes it easy, simple, and affordable to use force sensors in your projects!

This flexible pressure sensor is based on new nanometer pressure-sensitive materials supplemented by ultra-thin film substrate. Highly sensitive flexible nanometer materials achieve highly sensitive detection of pressure. It is also water-resistant! The same sensor is available in different force measurement ranges which lets you chose the perfect force sensor for your project.


  • Model: RP-S40-ST
  • Manufactured Type: Thin-film
  • Output signal: Analog
  • Pressure induction range: 20g-10kg
  • Trigger: 20 g, default resistance <200kΩ, trigger
  • Thickness: 0.45mm
  • Not trigger resistance: > 10MΩ
  • Activation time: <0.01s
  • Delay: +10%, (RF+-RF-)/FR+,1000g force
  • Response time: < 10ms
  • Size: 5 x 4cm / 1.97 x 1.57in
  • Weight: 2g


  • Detect & qualify press: Sense whether a touch is accidental or intended by reading force
  • Use force for UI feedback: Detect more or less user force to make a more intuitive interface
  • Enhance tool safety: Differentiate a grip from touch as a safety lock
  • Find the centroid of force: Use multiple sensors to determine the centroid of force
  • Detect presence, position, or motion: Of a person or patient in a bed, chair, or medical device
  • Detect liquid blockage: Detect tube or pump occlusion or blockage by measuring back pressure
  • Many other force measurement applications

Package Includes:

1 x 20g - 10kg Force & Pressure Sensor Flexible Precision Thin Film
