0-20kg Force & Pressure Sensor Flexible Precision Thin Film

₹349.00
In stock
SKU
PRO882

This is Force/Pressure sensor can measure a force of 0 to 20kg acting on it. It is simple and easy to use with Arduino, Raspberry Pi and other micrcontrollers. It uses Thin Film technology and is flexible. Great for general purpose projects applications. It has two pin interface which is simple and easy to use. It is works like a variable resistor. The resistance between the two output pins varies corresponding to the force acting on the sensor! Your micro controller - Arduino, Raspberry Pi, etc can measure this resistance using its inbuilt ADC and get the force acting on the sensor. This sensor makes it easy, simple and affordable to use force sensors in your projects!

This flexible pressure sensor is based on new nanometer pressure-sensitive materials supplemented by aultra-thin film substrate. Highly sensitive flexible nanometer materials achieve a high sensitive detection of pressure. It is also water resistant! The same sensor is available in different force measurement ranges which let you chose the perfect force sensor for your project.

Specifications:

  • Ultra thin
  • Simple and easy to integrate
  • Measuring Range: 0 to 20kg
  • Thickness: <0.25mm
  • Precision: ±2.5%(85% measuring range)
  • Repeatability: <±5.8(50% load)
  • Lifespan: >1million times
  • Initial Resistance: >10M?(no load)
  • Response Time: <1ms
  • Restore Time: <15ms
  • EMI: Not generate
  • EDS: Not sensitive
  • Sensing Area Outer Diameter: 9mm
  • Sensing Area Inner Diameter: 7.5mm
  • Pin Spacing: 2.54mm
  • Cost effective
Applications
  • Detect & qualify press: Sense whether a touch is accidental or intended by reading force
  • Use force for UI feedback: Detect more or less user force to make a more intuitive interface
  • Enhance tool safety: Differentiate a grip from a touch as a safety lock
  • Find centroid of force: Use multiple sensors to determine centroid of force
  • Detect presence, position, or motion: Of a person or patient in a bed, chair, or medical device
  • Detect liquid blockage: Detect tube or pump occlusion or blockage by measuring back pressure
  • Many other force measurement applications
