Walksnail Avatar HD Moonlight Kit 4K Night Vision FPV Camera Transmitter

Features:

• Ultra High-Definition Video - Supports 4K/60fps
• Starlight Camera Technology to improve image quality and performance in low-light scene shooting
• Enhanced Image Stability-Built-in EIS and supports Gyroflow technology, taking you to a smooth and stable video quality
• Expansive 160° Field of View
• Flexible Power Compatibility (7.4V-25.2V)
• Comes with silicone pads for mounting the camera, ensuring stability and minimising camera shake
• Supports manual shutter and manual ISO settings
• ND8 Filter Inclusion
• Dual Antenna Design
• Supports MicroSD cards up to 256GB and records at a maximum of 150Mbps

Specifications:

• Product: FPV Camera Kit

• Model: Moonlight Kit

• Camera Sensor: Starlight Sensor (Professional Night Vision)

• Field of View (FOV): Max 160°

• Aperture: F2.1

• ISO Range: 100 - 25600 (Manual Support)

• Recording Resolution:

  • 4K @ 60fps / 30fps

  • 2.7K @ 60fps / 30fps

  • 1080p @ 100fps / 60fps

• Video Format: MP4 (H.264)

• OSD: Canvas mode

• Stabilisation: Built-in EIS + Gyroflow Supported

• Bitrate: Max 150Mbps

• Input Voltage: 7.4V - 25.2V (2S to 6S LiPo Direct)

• Latency    Average: 22ms (High Frame Rate Mode)

• Frequency: 5.725-5.850GHz

• Transmitter Power (EIRP): FCC: <30dBm; CE: <14dBm; SRRC: <20dBm; MIC: <25dBm

• Storage: Micro SD Card Slot (U3 Recommended, Max 256GB)

• Mounting Holes:

  • VTX: 20x20mm / 25.5x25.5mm (M2)

  • Camera: 19mm x 19mm

• Weight: Camera + VTX: 38.5g (without antenna)

• Connector: JST1.0 x 4 Pin (Power in)

Package Includes:

• 1x Moonlight Camera (4K Night Vision)

• 1x Avatar V2 VTX Unit

• 1x ND8 Filter (Included)

• 2x V2 Antenna

• 1x Coaxial Cable (140mm)

• 1x Power Cable (4 Pin)

• 1x Screw Set (M2x4/5/6)

Frequently Asked Questions (FAQ)

1. Does this record 4K to the goggles? No, it records 4K/60fps to the onboard SD card on the VTX. The signal sent to the goggles is 1080p/100fps.

2. Is this compatible with DJI Goggles? No, Walksnail systems only work with Walksnail Avatar Goggles (X, L, VRX, etc.).

3. Can I power this directly from my battery? Yes, it supports 7.4V to 25.2V (2S to 6S). We recommend a capacitor (470uF+) on the power leads.

4. Does it support Gyroflow? Yes, the VTX records gyro data in the video metadata for post-processing stabilisation.

5. What is the "Moonlight" advantage? It uses a massive 1/1.8" sensor that sees much more light than a standard 1/3" FPV sensor.

6. Can I change the ISO and Shutter? Yes, this kit supports full manual camera settings via the Goggles OSD.

7. Is the camera "Micro" or "Nano" size? It is a standard 19mm x 19mm "Micro" size camera.

8. Does it come with an ND filter? Yes, an ND8 filter is included in the box for daytime flying.

9. What SD card is recommended? Use a high-speed U3 MicroSD card up to 256GB.

10. How many antennas does it use? It is a dual-antenna system (LHCP) for maximum signal penetration.

11. Does it have a microphone? Yes, it supports audio recording.

12. Is it compatible with 1S drones? No, the minimum voltage is 7.4V (2S).

13. Can I use my old Avatar V2 antennas? Yes, any LHCP IPEX-1 antennas will work.

14. How much does it weigh? 38.5g for the VTX and Camera together.

15. Does it support "Canvas Mode"? Yes, for full Betaflight/INAV OSD support.

16. Is the sensor "Rolling Shutter" or "Global Shutter"? It uses a rolling shutter optimized for high-speed flight.

17. What is the FOV? It provides a wide 160° Field of View.

18. Can I swap the coaxial cable? Yes, the cable between the camera and VTX is replaceable.

19. What is the maximum bitrate? 150Mbps for the onboard recording.

20. Does it get hot? Yes, digital VTXs get hot on the bench. We recommend "low power" mode until you are ready to arm and fly.
