2250KV SURPASS HOBBY 4076 Brushless Motor 150A ESC WATERPROOF IP65 βΉ25,099.00 This set is a complete combo of motors, propellers and ESCs required for a quadcopter.
RC BRUSHLESS MOTOR 2212 1000KV WITH PROPELLER ADAPTOR:
Weight 52 gm
Runs on 2-3 Cell Li-Po battery
ESC Requirement minimum 25A
Length 43.5mm with shaft
Diameter 28.5mm
Shaft Diameter 3.17mm
980 RPM/V no load speed
Free Load Current 2.5A
Maximum Efficiency : 86%
Thrust with 1047 Prop at 12V: 880gm
Included : Propeller Adaptor, Motor Mount, Mounting Screws
Propellers :
2 Normal props (Puller) + 2 reverse props (Pusher) - total 4 props.
10x4.5 inch ABS + Glass fiber plastic.
30A Brushless ESC:
High rate PWM
Low resistance
Sixteen cells Max (with BEC disabled)
User programmable brake
Low voltage auto setting based on battery
Throttle range self-adjusting
Soft start ramp up
Auto motor cutoff with reset
Runs motor in forward or reverse
Safe power arming program ensures motor will not run accidentally after turn on
Low torque start
Auto shut down when signal is lost
Constant Current: 30A
BEC 3A
Input Volt: 6V - 12V
Max Current: 40A
Low-Voltage Cutoff: Auto detect and set
Size: 56mm x 24mm x 8.5mm
Weight: 26g
Β
Note: The display is only for reference. Its not the actual Product.Β
