LM324DR General Purpose Amplifier SMD IC

₹399.00 Rs. 338.14 + 60.87 GST
In stock. 1-7 Day Delivery in India.
SKU
PRO2503

Description:

These LM324DR General Purpose Amplifier IC consist of four independent high-gain frequency-compensated operational amplifiers that are designed specifically to operate from a single supply over a wide range of voltages.

Specifications:

  • Internal frequency compensation
  • Common-mode input voltage range includes ground, allowing direct sensing near the ground
  • Low input bias and offset parameters
  • 2kV ESD Protection
  • 0.8mA Typical low supply current drain independent of supply voltage
  • 3mV Typical input offset voltage
  • 2nA Typical input offset current
  • 20nA Typical input bias current
  • 32V Differential input voltage range equal to the maximum-rated supply voltage
  • 100V/mV Typical open-loop differential voltage amplification
  • Green product and no Sb/Br

Applications:

  • Consumer Electronics
  • Sensing & Instrumentation
  • Motor Drive & Control
  • Test & Measurement.

Package Includes:

1 x LM324DR General Purpose Amplifier IC
