12V Digital Temperature Controller

₹749.00 ₹ 634.75 + 114.26 GST
In stock
SKU
PRO3604

1-7 Days Express Delivery in India Available

This is a temperature controller that can control a load based on temperature, Cooler, or other equipment by comparing a sensor signal with a set point value. Its mainly used in Domestic freezers, refrigerators, Industrial equipment, and other temperature-controlled systems.

This controller includes a relay that will turn on and off based on a temperature set point. The relay can be used to control loads like heaters, coolers, pumps, etc. The set points can be programmed onboard using the display and keypad. Multiple modes can be used like turning on relay after setpoint, below setpoint, between specific temperature range, etc.

It comes with easy to install panel mounting. Can be directely mounted in industrial panel cutouts.

Features:

  • Mini temperature controller
  • Clear LED display for better readability.
  • Wide temperature measuring range
  • Heating or cooling control.
  • Relay output (Common, NO).
  • High Control precision 0.1 centigrade

Applications:

  • Domestic freezer
  • Refrigerator
  • HeatPumps
  • Industrial chiller,
  • Steamer,
  • Industrial equipment and other temperature-controlled systems.

Operating Instructions:

Connect the Digital Temperature controller with the power supply and equipment to be controlled. Press the SET key once, and the display screen temperature flashes. Press+- to set the required temperature (press and hold+1 to quickly rise and fall). After the setting is completed, press SET to confirm and return. The output of the temperature controller is a Common and No with the rating of 20A relay, to meet various high-power loads operation connect through the suitable contactors.

  • Indicator light: flashing indicates the delay of refrigeration or heating startup, and constant light indicates that the relay is closed
  • Digital tube: LL indicates an open circuit of the sensor, please connect the sensor according to instructions; The temperature controller will forcibly disconnect the relay if HH is out of the measuring range
  • Display --- high-temperature alarm
  • Press and hold SET for 5 seconds to enter the main menu setting, and press+- to switch PO... P6, press and hold SET for 10 seconds, and the controller will automatically confirm and return without key action.

Function description:

  • P0: Refrigeration or heating mode
  • P1: Return difference setting
  • P2: Maximum temperature setting an upper limit
  • P3: Minimum temperature setting a lower limit
  • P4: Temperature correction
  • P5: Delay start time (unit: minute)

Digital Temperature Controller - Overview:

 Digital Temperature Controller -Overview

Package Includes:

1x 12V Digital Temperature Controller

More Information
Technical Details

Specifications:

  • Model: Digital Temperature Controller
  • Power Supply:12V DC
  • Temperature Control Range:-55°-100°
  • Maximum measured temperature: 100°
  • Resolution Ratio: 0.1°C(-9.9-99.9); 1°C(other range)
  • Color of Displaying: red/blue
  • Measurement accuracy: ±0.1°C
  • Control accuracy: 0.1°C
  • Sensor: NTC10K Waterproof sensor
  • Output: Common and NO
  • Output: Relay Contact Capacity 10A 220V / 20A 12V / 20A 24V
  • Environmental requirements: -10-60°C , humidity 20%-85%RH
  • Dimension:79mm *43mm*26mm
  • Panel Cut-out Size:73mm*39mm
  • Sensor wire: 1 meter

Dimensions:

Dimensions

Wiring Instructions:

Wiring Instructions
