CD4033 5-Stage Johnson Decade counter IC DIP-16 Package
₹210.00 ₹ 177.97 + 32.03 GST
In stock
SKU
PRO2941
- Counter and 7-segment decoding in one package
- Easily interfaced with 7-segment display types
- Fully static counter operation: DC to 6 MHz (typ.) at VDDÂ = 10 V
- Ideal for low-power displays
- Display enable output (CD4026B)
- "Ripple blanking" and lamp test (CD4033B)
- 100% tested for quiescent current at 20 V
- Standardized, symmetrical output characteristics
- 5-V, 10-V, and 15-V parametric ratings
- Schmitt-triggered clock inputs
- Meets all requirements of JEDEC Tentative Standard No. 13B, "Standard Specifications for Description of ’B’ Series CMOS Devices"
- Applications
- Decade counting 7-segment decimal display
- Frequency division 7-segment decimal displays
- Clocks, watches, timers (e.g. ÷60, ÷60, ÷ 12 counter/display)
- Counter/display driver for meter applications
Specifications:-
| Parameter | Specification |
| Part number | CD4033B |
| Technology Family | CD4000 |
| VCC (Min) (V) | 3 |
| VCC (Max) (V) | 18 |
| Bits (#) | 7 |
| Voltage (Nom) (V) | 5, 10, 15 |
| F @ nom voltage (Max)(MHz) | 8 |
| ICC @ nom voltage (Max)(mA) | 0.03 |
| tpd @ nom Voltage (Max)(ns) | 250 |
| IOL (Max) (mA) | 1.5 |
| IOH (Max) (mA) | -1.5 |
| Function | Counter |
| Type | Decade |
| Rating | See Data Sheet |
| Operating temperature range (C) | -55 to 125 |
| Package Group | PDIP|16 |
