CD4016 Quad Bilateral Switch IC DIP-14 Package

₹23.00 Rs. 19.49 + 3.51 GST
Features:- Wide supply voltage range: 3V to 15V Wide range of digital and analog switching: ±7.5 VPEAK “ON” resistance for 15V operation: 400Ω (typ.) Matched “ON” resistance over 15V signal input: ∆RON = 10Ω (typ.) High degree of linearity: 0.4% distortion (typ.) @ fIS = 1 kHz, VIS = 5 Vp-p, VDD−VSS = 10V, RL = 10 kΩ Extremely low “OFF” switch leakage: 0.1 nA (typ.) @ VDD − VSS = 10V TA = 25°C Extremely high control input impedance: 1012Ω (typ.) Low crosstalk between switches: −50 dB (typ.) @ fIS = 0.9 MHz, RL = 1 kΩ Frequency response, switch “ON”: 40 MHz (typ.)
In stock. 1-7 Day Delivery in India.
SKU
PRO2930
Specifications:- Parameter Specification VDD Supply Voltage −0.5V to +18V VIN Input Voltage −0.5V to VDD + 0.5V TS Storage Temperature Range −65°C to + 150°C Power Dissipation (PD): Dual-In-Line 700 mW Lead Temperature 260°C (For more detailed specification refer Data Sheet)
