ADS1115 IC 16 Bit ADC with I2C Interface ADS1115IDGSR

Description:

The ADS1113, ADS1114, and ADS1115 devices (ADS111x) are precision, low-power, 16-bit, I2Ccompatible, analog-to-digital converters (ADCs) offered in an ultra-small, leadless, X2QFN-10 package, and a VSSOP-10 package. The ADS111x devices incorporate a low-drift voltage reference and an oscillator. The ADS1114 and ADS1115 also
incorporate a programmable gain amplifier (PGA) and a digital comparator. These features, along with a
wide operating supply range, make the ADS111x well suited for power- and space-constrained, sensor
measurement applications.

Specifications:

• Small VSSOP Package: 3.00 mm × 3.00 mm
• Wide Supply Range: 2.0 V to 5.5 V
• Number of Pins: 10
• Conversion Rate: 860 S/s
• Integral Nonlinearity (INL): 1 LSB
• Interface: SPI
• Min Supply Voltage (DC): 2 V
• Number of Inputs: 4
• Four Single-Ended or Two Differential Inputs (ADS1115)
• Programmable Comparator (ADS1114 and ADS1115)
• Operating Temperature Range: –40°C to +125°C

Applications:

• Portable Instrumentation
•  Battery Voltage and Current Monitoring
•  Temperature Measurement Systems
•  Consumer Electronics
•  Factory Automation and Process Control

Package Includes:

1 x ADS1115 IC
