AC Contactors Chint NC1-6504 4P 240V

₹5,775.00 Rs. 4894.07 + 880.93 GST
In stock. 1-7 Day Delivery in India.
SKU
PRO3050
Chint AC contactors, Specially designed for remote making & breaking circuits to protect circuit from over-load when assembling with thermal over-load relay. Maximum allowable current up to 65Amps, and is able to readily and frequently turn on or off the power supply for high-current power appliance, e.g. 240 V AC Input.


Specifications:
Parameter Description
Pole 4.0
Rated Coil Voltage 240V AC
Input Contacts 4NO
Frequency 50/60 Hz
Rating AMP 65 Amp
kW Rating 18.5
Electrical life ( x 10^3Operations) 600
Mechanical Lifetime(x 10^6) 8


General Description:
Parameter Description
Electric ratings AC50/60Hz, 240V, 65A
Utilization category AC-3
Altitude 2000m
Ambient temperature -5 Degree C ~+40 Degree C
Mounting category III
Mounting conditions Inclination between the mounting plane and the vertical plane should not exceed 5
Standard IEC/EN 60947-4-1


Package Includes:
  • 1 x AC CONTACTORS CHINT NC1-6504 4P 240V

* Product Images are shown for illustrative purposes only and may differ from actual product.
