240 RPM 12V High Torque Square Gearbox DC motor For DIY Robotics
It is a Square Gear DC Motor of 240 RPM featuring metal gearbox for driving the shaft of the motor, so it is a mechanically commutated electric motor which is powered from DC supply. The Square Gear DC Motor are known for their massive torque-speed characteristic.
The Square Gear DC Motor comes with four M4 mounting holes. The shaft of the motor equips metal bushes which makes these Square Gear DC Motor Shaft wear resistant. The motor will run smoothly between the voltage range 6 to 18 V DC and give you 240 RPM at 12V supply.
The Square Gear DC Motor gives very good torque at an affordable price hence they are widely applicable in Central air conditioning valve, Amusement equipment, Coin refund devices, Grill, Oven; Peristaltic pump, ATM bank automatic system, Medical equipment, Office equipment, Household appliance, Automatic actuator and many more.
Also, they are best suitable for developing Robust and capable robots or robotic platform, various automation purposes.
Power Supply: 12V DC
Rated Torque: 63.9 N-cm
8mm Dia shaft with M4 thread hole
Gearbox diameter: 70 mm
Motor Diameter: 42 mm
Length without shaft: 106 mm
Shaft length: 27mm
Recommended to be used with DC Motor Driver 20A or Dual DC Motor Driver 20A
The motor has sturdy construction.
Shaft equips metal bushes for long life.
It comes with High-Quality gears.
Lightweight and compact-sized motor with high performance.
The Shaft is D type hence wheel/ coupling arrangement is simple.
The motor is useful for hobbyists and for DIY projects.
Note : Please note that this motor will have a +/- 10% error in the RPM.
