2.54mm Pitch PCB Straight Foot PBT Terminal Block Connector

₹49.00 Rs. 41.53 + 7.48 GST
In stock. 1-7 Day Delivery in India.
SKU
PRO1867

Use these screw terminals for connections that need frequent changing and to ensure that it is well secure mechanically and electrically. Its is a PCB mountable type terminal block with a power rating as high as 250V/10A.

Material
Shrapnel: Stainless steel
Pin header: Brass , Tin plated
Housing: PA66 , UL94V-0

Electrical
Rated voltage: 250V
Rated current: 10A
Wire range: 26~18AWG 1.0mm²
Contact Resistance: 20 m Ω
Insulation resistance: 500MΩ/DC500V
Withstand voltage: AC1300V / 1 min

Mechanical
Temp. Range: -40 ° C ~ + 105 ° C
Soldering: 250° C±5° C for 5S
