SIM800L V2 Wireless GSM GPRS Module Quad-Band with Antenna

₹899.00 ₹ 761.86 + 137.13 GST
In stock
SKU
PRO2416

Description:

SIM800L V2.0 GSM/GPRS Module is a QUAD-BAND GSM/GPRS module that is compatible with Arduino. The module works to add both GSM features (voice call or SMS) and GPRS features. The advantages of these modules are the VCC and TTL serial levels that have 5V voltage, so you can directly connect it to Arduino or another minimum system with 5V of the voltage level.

There are so many GPRS/GSM modules on the market that needs a 5V regulator and level converter circuit, while SIM800L V.2 GSM/GPRS module already has a built-in regulator circuit and TTL level converter on the board.



Pin Description:-

5v: Power interface Power the module CONNECT TO DC 5v
GND: Connect to GND.
VDD: TTL UART interface The TTL UART serial interface, you can connect the MCU like 51MCU or ARM or MSP430 directly. The pin of VDD is used to match the voltage of the TTL.
SIM_TXD: SIM module Transmitter.
SIM_RXD: SIM module Receiver.
GND: If this pin is unused, keep it open.
RST: RST the module, if this pin is unused, keep it open.



Specifications:-

  • Interface Type: TTL UART
  • Baud Rate: Adaptive (default), Support2400-115200
  • Input Supply Voltage (VDC):5 ~ 20
  • Power Interface:2.54mm Pin Header/MICRO USB
  • Antenna Interface:ASMA, IPX
  • Network support: Quad-Band 850/900/1800/1900 MHz works on GSMnetworks in all countries across the world.
  • TTL serial interface compatible with 3.3V and 5V MCU
  • The small size is suitable for all kinds of sleeve belt types and embedded.


Package Includes :

1 x SIM800L V2 Wireless GSM GPRS Module Quad-Band with Antenna
