Flexible 6-in-1 Splitter Cable Connector for EL Wire - Multi-Port Power Extension

Specifications:

• Input: 1 x JST-SM 2-Pin Male (Connects to Inverter)
• Output: 6 x JST-SM 2-Pin Female (Connects to EL Wires)
• Cable Type: Flexible Ribbon Style
• Total Length: ~25cm
• Wire Gauge: 24AWG standard
• Compatibility: Works with all standard  EL Wires.

Key Applications:

• Wearable Tech: Powering multiple limbs on a glow-suit from a single waist-mounted battery pack.
• Automotive Styling: Distributing light to four door panels and a dashboard from one 12V inverter.
• Home Decor: Creating multi-color neon wall art.
• Architectural Models: Highlighting different structural levels simultaneously.

Project Evolution

• Past Projects (Prerequisites): If you've mastered a basic single-wire setup using a standard AA battery inverter, you’re ready for this.
• Feature Upgrade: This splitter unlocks "High-Density Lighting." It allows you to mix and match different colors of EL wire on a single circuit, creating complex gradients and patterns that were previously impossible without multiple power sources.
• Effort/Requirements: Beginner Friendly. Simply plug and play. Ensure your inverter is rated for the total length of all 6 wires combined.

 Virtual Technician & Wiring

• ⚠️ High Voltage Warning: EL Inverters output high-frequency AC (approx 100V). Never touch exposed pins while the power is on.
• Pin Mapping: Standard JST-SM 2-Pin. The polarity is reversible for EL wire as it uses AC, but ensure the clips are securely locked to prevent arcing.
• Pro Tip: If using only 3 or 4 ports, we recommend covering the unused female ends with electrical tape to keep dust out.

Package Includes:

1 X Flexible 6-in-1 Splitter Cable Connector for EL Wire - Multi-Port Power Extension

Frequently Asked Questions (FAQ)

1. Will this make my EL wires dimmer?
   If your inverter is rated for the total length of all wires, brightness remains constant.

   2. Can I use this with a 3V battery inverter?
   Yes, provided the total wire length doesn't exceed the inverter's capacity.

   3. What happens if I leave some ports empty?
   Nothing; the circuit remains open on those ports without issue.

   4. Is this compatible with 12V car inverters? Yes, it is compatible with any standard JST-output inverter.

   5. Can I daisy-chain two of these together? Not recommended, as it significantly increases resistance.

   6. Are the wires heat-resistant? They are rated for standard EL operating temperatures.

   7. Does it work with EL Tape or EL Panels? Yes, if they use the standard 2-pin JST-SM connector.

   8. What is the maximum current this can handle? EL systems use very low current; this cable is rated for up to 500mA.

   9. Can I cut and shorten the wires? Yes, but ensure you insulate the ends perfectly.

   10. Is this waterproof? No, the connectors are not IP-rated.

   11. Do I need to solder anything? No, it is a 100% solderless plug-and-play solution.

   12. Why are the wires black? To blend into shadows and highlight only the glowing EL wire.

   13. How do I know if my inverter is powerful enough? Add the lengths of all 6 wires (e.g., 6 x 1m = 6m) and check your inverter’s "Max Length" rating.

   14. Will it work with different brands of EL wire? Yes, standard 2-pin JST is universal in the EL industry.

   15. Does the splitter get hot? No, it should remain cool during operation.

   16. Can I mix colors on one splitter? Yes! Red, Blue, Green, etc., can all run off the same splitter.

   17. Is the cable flexible? Yes, it is highly flexible for tight corners.

   18. Can I use this for LED strips? No, this is specifically designed for high-voltage AC EL wire.

   19. What is the connector pitch? 2.54mm (Standard JST-SM).

   20. Can I use this to sync lighting to music? Yes, if your inverter has a sound-activation feature, all 6 wires will sync together.
