EDR-120-12 Mean well SMPS - 12V 10A 120W Din Rail Metal Power Supply

₹2,465.00 Rs. 2088.98 + 376.02 GST
Availability: Out of stock
SKU
PRO3008

This is a high quality AC to DC power supply, which uses the SMPS technology for better efficiency and reliability. It outputs 12V and has maximum load capacity of 10A.

Key Specifications:-

  • Output Voltage          12V
  • Type                  DIN Rail Type
  • Approx. Wattage  120W
  • Features                  Standard
  • Series                  EDR(Economical)
  • Mechanical Form  DIN Rail
  • Warranty                  2 Years Warranty
  • IP Level                  Non-Waterproof
  • Input Voltage          100-240V auto-select


Features:-

  • Universal AC input / Full range
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Cooling by free air convection
  • Can be installed on DIN rail TS35 / 7.5 or 15
  • UL508 (industrial control equipment) listed
  • EN61000-6-2 (EN50082-2) industrial immunity level
  • 100% full load burn-in test
  • Low cost
  • 3 years warranty for NDR series
  • 2 years warranty for EDR series

Specifications:-

AC input voltage range 90~264VAC; 127~370VDC
AC inrush current (max.) Cold start, 35A at 230VAC
DC adjustment range 12V: 12~14V, 24V: 24~28V, 48V: 48~55V
Current adjustment range 10%~100% rated output current adjustable by 1~10Vdc, PWM signal or resistance
Overload protection 105%~130% Constant current limiting, auto-recovery
Over voltage protection 14V: 14~17V, 24V: 29~33V, 48V: 56~65V Shut down o/p voltage, re-power on to recover
Over temperature protection Shut down o/p voltage, re-power on to recover
Withstand voltage I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature -20~+60!aC (refer to output derating curve
Safety standards UL60950-1, TUV EN60950-1 approved
EMC standards EN55022 classA, EN61000-3-2(125W for EDR-150),3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2(EN50082-2)
Connection (screw DIN terminal) I/P: 3 poles, O/P: 4 poles
Dimension (LxWxH) (mm) 40x 125.2x 113.5
