5W High Power UV LED - 395nm Ultraviolet (20mm Aluminum Star PCB)

Specifications:

• Power Rating: 5 Watts
• Peak Wavelength: 395nm
• Forward Voltage (Vf): 3.4V - 3.8V DC
• Forward Current (If): 1000mA - 1200mA (Max)
• Luminous Flux: High Brightness (Visible Purple + UV)
• Viewing Angle: 120° - 140°
• PCB Diameter: 20mm (Star Type)
• PCB Material: Aluminum Substrate
• Life Span: > 50,000 Hours (If kept < 60°C)

Key Applications & Projects

• Scorpion Hunting: The high intensity and wider beam (flood) make it excellent for spotting scorpions from a distance outdoors.
• Stage & Party Lighting: Creates powerful "Glow in the Dark" effects for fluorescent paints and clothes.
• Aquarium Lighting: Acts as a "Moonlight" or Actinic light to make corals fluoresce efficiently.
• General Curing: Capable of curing standard UV resins and nail gels (though slightly slower than 385nm).
• Leak Detection: Works with standard automotive UV dyes.

Project Evolution

• Prerequisites: Users upgrading from 3W LEDs or 5mm LEDs.
• The Upgrade: This 5W unit allows for Long Throw applications. Put this behind a lens or reflector, and you can illuminate fluorescent objects 20-30 feet away, whereas a 3W LED might only reach 10 feet.
• Effort Level: Intermediate. Requires a high-current driver and active cooling considerations.

Virtual Technician: Wiring & Safety Guide

⚠️ CRITICAL WARNINGS:

• Heat: This is a heater as much as it is a light. Ensure solid contact with a heatsink using thermal paste.
• Eyes: Do not stare at the beam. The visible purple light is bright, but the invisible UV energy is even stronger.

Wiring Pinout:

• (+) Pad: Positive Input.
• (-) Pad: Negative Input.
• Driver: Requires a 5W LED Driver (1000mA - 1200mA). Do not connect directly to 12V or 5V sources.

​Packages include:

1 X 5W High Power UV LED - 395nm Ultraviolet (20mm Aluminum Star PCB)

Frequently Asked Questions (FAQ)

1. How does this compare to the ₹ (3W) version?
   This version is 5 Watts, meaning it can handle nearly double the power (1200mA vs 700mA). It is significantly brighter and covers a larger area.
2. How does this compare to the (385nm) version?
   This (395nm) is cheaper and has a more visible purple glow. The 385nm version is tuned specifically for faster curing. If you are just making things glow or hunting scorpions, save money and buy this 395nm one.
3. Will this cure UV resin?
   Yes, it works well for most standard hobby resins and nail gels. It might take slightly longer than the 385nm version, but it gets the job done.
4. Do I need a heatsink?
   YES. You cannot run a 5W LED without a large heatsink. The star board alone is not enough.
5. Can I use a 12V adapter?
   Not directly. You need a Driver that takes 12V and limits the current to 1.2A. If you connect 12V directly, the LED will explode.
6. Is this good for scorpions?
   Yes, it is excellent. Scorpions glow bright green/cyan under 395nm light, and the extra power helps you see them from further away.
7. Can I use it for forensics/banknotes?
   It works, but the strong visible purple light can wash out faint details. For forensics, the 365nm version is much better.
8. What is the max current?
   We recommend running it at 1000mA - 1200mA. The absolute max is usually around 1400mA, but heat becomes very difficult to manage.
9. Is the light visible?
   Yes, very. It emits a bright, deep violet light.
10. Can I dim it?
    Yes, if you use a dimmable LED driver (PWM).
11. Is the PCB electrically isolated?
    Yes, the aluminum base is isolated from the electrical pads.
12. Can I use thermal tape?
    For 5W, we strongly recommend Thermal Paste and Screws. Tape might not transfer heat fast enough.
13. Why use a 20mm board?
    The 20mm "Star" shape is easy to screw down onto heatsinks and provides good surface area for soldering wires.
14. Does it work for pet stains?
    Yes, dried urine will glow, but again, the purple visible light might reduce contrast compared to 365nm.
15. Is it waterproof?
    No.
16. Can I use a lens?
    Yes, standard 20mm lenses fit this LED.
17. How hot can it get?
    Without a heatsink? >100°C in seconds. Keep it under 60°C for long life.
18. Can I run it on batteries?
    Yes, but you need a driver. A single 18650 won't power it fully (voltage drop). Two batteries + a buck driver is best.
19. Is this a "Blacklight"?
    Yes, 395nm is the classic blacklight wavelength.
20. Why is it cheaper than the others?
    395nm chips are the most common and easiest to manufacture in high volumes.
