100 RPM High Torque DC Geared Motor Side Shaft for Robotics

₹599.00 Rs. 507.63 + 91.37 GST
In stock. 1-7 Day Delivery in India.
SKU
PRO2381

Use this gear motor for your robotics and automation projects. Uses a good quality DC Motor with high-quality gearbox for the best performance. Can be used for robot drives, actuators, robot arms, counting and sorting machines, etc. These motors are available in a wide range of RPM and Torque ratings and you can choose the one best suited for your application.

A geared DC Motor has a gear assembly attached to the motor. The speed of the motor is counted in terms of rotations of the shaft per minute and is termed as RPM. The gear assembly helps in increasing the torque and reducing the speed. Using the correct combination of gears in a gear motor, its speed can be reduced to any desirable figure. This concept where gears reduce the speed of the vehicle but increase its torque is known as gear reduction.

Specifications:

  • Output RPM: 100 rpm
  • Stall Torque: 2.5 Kg/cm
  • Stall Current: 750 - 800 ma
  • Motor body Length: 75mm
  • Motor Body Diameter:35mm
  • Material: Cast Iron
  • Shaft diameter: 6mm
  • Working Voltage: 12V

Note: Product model may vary slightly as stock lasts.

Applications:

The main application of this motor is Pan/ Tilt cameras, auto shutter, welding machines, water meter, grill oven, Floor cleaning machine, garbage disposers, household appliances, Slot machines, Money detector, automatic actuator, coffee machine, Towel dispenser, lighting, Coin refund devices, Peristaltic pump and many more.

Package Includes:

  • 1 x 100 RPM High Torque DC Geared Motor Side Shaft
