Read Article βThese Rocker Switches house a button for operation that can be pressed on either end to connect or disconnect an electrical circuit. They are often used as ON/OFF switches on the main power supplies for electronic devices. They are also known as see-saw switches
ProMax Rocker Switches consist of an operation button, sealing rubber, semi-elliptical spring, internal case, lid, cover, contacts, and terminals. This ON / OFF switch trips once pressed on one side which means one side of the switch is raised while another side is depressed. There are two symbols on this switch where one is a circle symbol which indicates OFF & the other is a line which indicates ON. Once this switch is turned ON, then the contacts will be closed. So in this position, the contacts will be touched to allow the current flow between them. Similarly, once the switch is turned OFF, the contacts will be pulled into an open position. Once these contacts are in an open position, they will not touch each other, so there is no current flow between them.
This ProMax Rocker Switch is a DPST (Double pole Single throw) with 12-24V Red LED and a current rating of 16A. This switch has two main components an actuator and a set of contacts. An actuator in the switch at the front side moves & applies force to the contacts to turn ON & OFF the switch whereas the set of contacts at the back for connecting circuits and LED will determine whether the switch is set to ON/OFF with Led Illumination. It comes with tabs on the top and bottom which secure it onto an enclosure without the need for any screws. These switches are mainly used in display monitors, surge protectors, computer power supplies, and DIY Projects.
Note:
Features:
Applications:
Specifications:
Package Include :
1 x ProMax 12-24V Red Led 16A DPST Rocker Switch 2 Position ON OFF Latching Control KCD4 IP67
Products vary from lot to lot. Except for slight variations with the actual product, Contact us for Exact photos or specifications before ordering.
The pictures shown here are for illustration purposes only.
This video describes the application of a Similar Rocker Switch with a 12V Red LED
| Technical Details |
ProMax 16A 250V Rocker Switch ON OFF -Dimensions
ProMax 16A DPST Rocker Switch ON OFF -Wiring Interface |
|---|
