EM4100 RFID Card Reader Module RDM6300 125KHz
Note: This product has been discontinued. New Alternative - RC522 RFID Reader
RDM6300 125KHz EM4100 RFID Card Reader Module is designed for reading code from 125KHz card compatible read-only tags and read/write card. It can be applied in office/home security, personal identification, access control, anti-forgery, interactive toy and production control systems etc. RDM6300 Series non contact RFID module, use the advanced RF receiving circuit and embedded MCU design, combing with high efficient decoding algorithm, to finish the data receive of EM4100 and all the compatible cards.
One of the coolest part of IoT project must be the identification technology, 125Khz RFID module UART is the most popular RFID module. By connecting this RFID module to Arduino or Raspberry Pi, you are able to build projects that can be used in office/home security, personal identification, access control, anti-forgery, interactive toy and production control systems etc.
This module is easy to use, serial port connect to Arduino MCU after power up, when RFID card enter into card reading range, this module will send the card number to Arduino by UART You can further connect relay Arduino shield to your Arduino in order to enable the simple door keeper controlling system.
Operating Frequency 125KHZ
Baud Rate 9600
Interface TTL level RS232 format
Working voltage DC 5V(+/-5%)
Working current <50mA
Receive distance 20~50mm
Working temperature -10°C ~ +70°C
Storage temperature -20°C ~ +80°C
Wiring size: 46*32*3mm
PCB size 38.5 x 19 x 9 mm
Support external antenna
Maximum effective distance up to 50mm
Less than 100ms decoding time
Support EM4100 compatible read only or read/write tags
Built-in external bi-color LED and buzzer driver
Small outline design
