CD4543 BCD to 7 Segment Decoder IC DIP-16 Package

₹41.00 Rs. 34.75 + 6.26 GST
In stock. 1-7 Day Delivery in India.
SKU
PRO2975

Features:-

  • Display blanking of all illegal input combinations
  • Latch storage of code
  • Capability of driving two low power TTL loads, two HTL loads, or one low power Schottky load over the full rated-temperature range
  • Pin-for-pin replacement for the CD4056B (with pin 7 tied to VSS)
  • Direct LED driving capability
  • 100% tested for quiescent current at 20 V
  • Maximum input current of 1 µA at 18 V over full package-temperature range; 100 nA at 18 V and 25°C
  • Noise margin (full package-temperature range) =
        1 V at VDD = 5 V
        2 V at VDD = 10 V
        2.5 V at VDD = 15 V
  • 5-V, 10-V, and 15-V parametric ratings
  • Meets all requirements of JEDEC Tentative Standard No. 13B, "Standard Specifications for Description of ’B’ Series CMOS Devices"
  • Applications:
    • Instrument display driver
    • Dashboard display driver
    • Computer/calculator display driver
    • Timing device driver (clocks, watches, timers)



Specifications:-

Parameter Specification
Part number CD4543B
Technology Family CD4000
VCC (Min) (V) 3
VCC (Max) (V) 18
Bits (#) 7
Voltage (Nom) (V) 5, 10, 15
F @ nom voltage (Max) (MHz) 8
ICC @ nom voltage (Max) (mA) 0.3
tpd @ nom Voltage (Max) (ns) 400
IOL (Max) (mA) 1.5
IOH (Max) (mA) -1.5
Function Decoder
Type Standard
Rating See Data Sheet
Operating temperature range (C) -55 to 125
Package Group PDIP|16
Configuration 04:07
Package size: mm2:W x L (PKG) 16PDIP: 181 mm2: 9.4 x 19.3 (PDIP|16)
Digital input leakage (Max) (uA) 5
ESD CDM (kV) 0.75
ESD HBM (kV) 2
