APV-25-12 Mean Well SMPS 12V 2.1A 25.2W LED Power Supply

₹949.00 ₹ 804.24 + 144.76 GST
In stock
SKU
PRO3007

This is a high quality AC to DC power supply, which uses the SMPS technology for better efficiency and reliability. It outputs 12V and has maximum load capacity of 2.1A.

Key Specifications:-

  • Output Voltage          12V
  • Type                  LED & Waterproof
  • Approx. Wattage  25W
  • Features                  Standard
  • Series                  APV (Economical)
  • Mechanical Form  Plastic
  • Warranty                  2 Years Warranty
  • IP Level                  IP42
  • Input Voltage          100-240V auto-select

Features:-

  • Universal AC input / Full range
  • Fully isolated plastic case
  • Protections: Short circuit / Overload / Over voltage
  • Constant voltage design (C.V. mode)
  • IP42 design
  • Withstand 300VAC surge input for 5 seconds
  • Class 2 power unit / Pass LPS
  • Isolation class II, no F.G.
  • Cooling by free air convection
  • 100% full load burn-in test
  • Low cost, high reliability
  • Suitable for LED lighting and moving sign applications
  • 2 years warranty

Specifications:-

  • AC input voltage range 90~264VAC ; 127~370VDC
    AC inrush current Cold start, 45A at 230VAC
    Overload Range >105% rated output current
    Protection Type Hiccup up mode, auto-recovery
    Over voltage protection 110%~145% rated output voltage
    Withstand voltage I/P-O/P: 3kVAC
    Working temperature -30~+70OC (refer to output derating curve)
    Vibration 10~500Hz, 2G 10 minutes /1 cycle, period for 60 minutes each along X, Y, Z axes
    Safety standards UL8750 approved (except for APC-25-350&APC-35-350/500);Design refer to TUV EN60950-1
    EMC standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11
    Connection Input UL rated, 18AWGx2C (15cm)
    Connection Output UL rated, 18AWGx2C (15cm)
    Dimension (LxWxH)(mm) 84x 57x 29.5
