400W 15A DC-DC Boost Converter Step-up Module Constant Current LED Driver

₹849.00 ₹ 719.49 + 129.51 GST
In stock
SKU
PRO1386

Description:


The 400W 15A DC-DC Boost Converter Step-up Module is a handy power accessory board that allows you to fine-tune the amount of power your project receives. This converter can take an input voltage of anywhere from DC 8.5V-50V which can then be regulated to an output voltage between 10-60V continuously adjustable. With a wide input voltage range from 8.5V-50V, the Step-up converter can accurately adjust the output voltage and current.  The Boost module has 2 heat sink that could enhance heat dissipation. Wiring is convenient with these large current 15A screw terminals.


Specifications:

  • Module name:400W boost constant current module
  • Module properties: non-isolated step-up module (BOOST)
  • Input voltage: DC 8.5V-50V
  • Input current: 15A (MAX) exceeds 8A please enhance heat dissipation
  • Quiescent current: 10mA (12V liter 20V, the output voltage, the higher the current will increase too quiet)
  • Output voltage: 10-60V continuously adjustable
  • Constant] range: 0.2-12A
  • Temperature: -40 to + 85 degrees (ambient temperature is too high, please enhance heat dissipation)
  • Operating frequency: 150KHz
  • Conversion efficiency: up to 96%
  • Overcurrent protection: yes
  • Input reverse polarity protection: no
  • Installation: 4 2.55mm screw holes
  • Connection method: Connection Output
  • Module size: 67mm X48mm X 28mm (LxWxH)
  • Single module: 60 g


Applications:

  •  DIY a power supply, 12V input and output  12-50V adjustable.
  •  The power supply for your electronic device, according to your system can set the output voltage value.
  •  As the car power supply for your laptop, PDA, or a variety of digital products supply.
  •  DIY a mobile notebook power supply: 12V coupled with a high-capacity lithium battery pack.
  •  Driving high-power LED lights.


Package Includes:



1PC*400W Boost Converter
