Robot Chassis 2 Wheel Drive Frame with Motors DIY Car Kit 2WD
This DIY 2 Wheel Drive Robot Chassis is the perfect mechanical platform for your robotics projects. This kit includes all the hardware and mechanical components required to build your robot, including motors, wheels, chassis, nut and bolts, etc. Just add your electronics - Arduino/Raspberry Pi and Motor Driver and you can start programming your robot. It offers a large space with predrilled holes for mounting sensors and electronics as per your requirement. This robot chassis lets you get your mechanical platform ready in minutes and quickstart your robot building process. Allows you to spend your time and effort on programming your robot rather than designing and fabricating your own custom platform.
Wheeled Robots are most popular robot platforms and are easy to run, maintain and use. Simple to build and program, this kit is the simplest robot platform. Highly recommended for beginners and novice users. Building robots using this wheeled kit is fun and a great learning experience too. This 2WD Robot Kit costs less, is simple to build, maintain and program. Our 4WD Kit lets you go faster, carry more weight, and carry bigger load compared to the 2WD Kit. You can build line following robots, obstacle avoiding robots, maze solvers, and other robots using this kit.
We have carefully selected the high quality motor, wheel and platform combination for the best performance. All 2 Motors come with matching wheels and mounting hardware. The motors also include encoder discs to measure speed and the distance traveled by the robot. Since this is a very popular robot kit, numerous assembly and usage instructions are available on the internet. Assembly manual is included in the kit too.
The Robot Car Kit Chassis 4WD is made of imported acrylic with high-precision laser cutting.
Can use with other devices to realize function of tracing, obstacle avoidance, distance testing, speed testing, wireless remote control.
Size: approx. 20 x 14cm(L x W); Wheel Size:6.5cm (Dia.) x 2.7cm (H)
motor power supply is 3V~6V. All the parameter above is tested without load.
The car Chassis is transparent, you need to tear out protective paper
1 x Car Chassis
2 x Gear Motor 1:48
2 x Car Tire
2 x Speed Encoder
4 x Fastener
1 x Universal Wheel
1 x Screwdriver
1 x Four Battery Box (Batteries not included )
All Necessary Screw And Nut
- Operating Voltage: 3-6V DC
- Wheels: 6cm
- Bottom Plast Thickness of about 3 mm
- Kit Includes a 4 AA battery box and battery case. (Batteries are not included.)
- Included motor encoder Can be used for distance measurement, velocity.
- Tyre Diameter: 6.6cm
- Simple mechanical structure, easy for installation.
- Adopts 2 DC motors for optimal power, speed and load capacity
- Large and stable Chassis, easy for expansion.
- Speed test encoding disk.
- When Powered at 6V, this robot can reach speeds upto 0.3m/sec
- 20 slot Speed Encoder, more accurate than other 6 or 10 slot encoders
- This kit is great for DIY Learning, Academic Research, Hobby Projects and Robot Competitions
- 1 x 4WD Robot Car Chassis (Acrylic)
- 2 x High Power DC Motor
- 2 x 20 line encoder disc for the motor
- 2 x Wheels
- 1 set x Fastener
- Some screw, nut and copper spacers required for assembly
- Assembly Manual
Note: This kit includes unassembled mechanical wheeled frame parts only. It requires assembly by the user. Robot Chassis - Frame and Motors are included only. Electronics, Controller, Motor Driver, Battery and other required products are not included and are to be added by the user separately as per requirement. Learning Resources
